The importance of toner cartridges and toner Before talking about toner cartridges, it is necessary to briefly understand the relationship between toner cartridges and laser printers. Let us first look at the working principle of laser printers! Taking the working principle of the black-and-white laser printer as an example, when the computer sends data to the printer through the cable, the printer first temporarily stores the received data in the cache, and then receives a complete piece of data before sending it to the printer's processor for processing. The data is processed into a set of signals similar to a data table that can drive the motion of the print engine. For laser printers, these sets of signals are a set of pulse signals that drive the laser head to operate. Well, the laser printer started working. In fact, its core technology is electronic imaging technology, which combines the principles of imaging and electronics to generate images. The core component is a toner cartridge that can be photosensitive. The laser light emitted by the laser emitter is irradiated on a prismatic mirror. As the mirror rotates, the light is swept from one end of the drum to the other end (passing through various focusing lenses to scan the surface of the drum) The dots are very small. The toner cartridge rotates in steps of 1/300 inch or 1/600 inch, and the scan is performed on the next line. In fact, the toner cartridge is a cylinder coated with an organic material on its surface, which is pre-charged, and when it is irradiated with light, a resistance reaction occurs in the irradiated portion.

The data signal sent by the computer controls the emission of the laser and scans the light on the surface of the cartridge.

Constantly changing, so that some places are exposed, the resistance becomes smaller, the electric charge disappears, and some places are not exposed to light, and the electric charge remains. Finally, the surface of the toner cartridge forms a latent image composed of electric charges. How does the latent image become a truly printed image? Toner plays a key role. The toner is essentially a charged fine plastic particle whose charge is opposite to the polarity of the charge on the surface of the drum. When the surface of the charged drum passes through the applicator roller, it has a charge. The toner particles are adsorbed on the part, and the latent image becomes a real image. While the toner cartridge is rotating, another set of drive system feeds the paper, and the paper has a charge that is the same polarity but much stronger than the surface of the drum. Then the paper passes through the toner cartridge, and the toner on the surface of the drum is attracted. On top of the paper, the image is formed on the surface of the paper. At this point, the toner and printer are just

* The attractiveness of the charge is combined. Before the paper is sent out of the printer, the plastic toner is melted by high temperature and solidified on the surface of the paper during cooling. After the toner is attached to the paper, the surface of the drum continues to rotate, passing through a cleaner, and the remaining toner is removed to enter the next printing cycle. It can be seen that the toner cartridge plays an important role in this process. In fact, the toner cartridge is the most critical component of a laser printer. Because it not only determines the quality of the print, but also determines the cost of printing. This is because in laser printers, more than 70% of the imaging components are concentrated in the toner cartridge, and the quality of the print is actually determined to a large extent by the toner cartridge. The toner cartridge is also a consumable item in the printer. After using it for a certain period of time and reaching a certain number of sheets, it needs to be replaced. Therefore, there is a lot of knowledge about choosing a toner cartridge suitable for a laser printer.
